Commander 3XL – Heavy Lift UAS

22 Pounds of Payload. 55 Minutes of Presence.

The Commander 3XL is a heavy-lift multi-role UAS built for operators who need serious payload capacity without sacrificing endurance or operational flexibility. With a 22lb payload capacity and 55-minute hover endurance, it carries mission-critical equipment – from FLIR thermal cameras and RGB mapping systems to surveillance gimbals – across a wide range of ISR, reconnaissance, and public safety operations.

Foldable arms enable rapid deployment and compact transport, while compatibility with multiple radio systems, including DTC Blue SDR, extends operational range beyond 10km. Built to handle wind, temperature extremes, and high-density altitude environments up to 8,000ft ASL.

Draganfly is one of the longest-standing drone manufacturers — its products are backed by highly experienced engineering and training teams, offering rapid integration and development capabilities to support your mission.

Commander 3XL Spec Sheet

Customer Sales Representative

Unmanned Systems Catalog

Description

When the mission demands serious payload capacity without sacrificing endurance or operational flexibility, the Commander 3XL delivers.

Mountain Horse Solutions is proud to feature this heavy-lift, multi-role UAS, built for operators who need to carry mission-critical equipment into demanding operational environments. With a 22 lb (10 kg) payload capacity and up to 55 minutes of hover endurance, Commander 3XL provides the lift, persistence, and versatility needed across ISR, reconnaissance, and public safety missions.

Mission Highlights:

• Up to 22 lbs (10 kg) payload capacity
• Up to 55 minutes of hover endurance
• Up to 50 minutes of flight endurance
• Maximum speed of 38 knots (72 km/h)
• 10 km operational range with DTC Blue SDR
• Compatible with FLIR thermal cameras, RGB cameras, and surveillance gimbals
• Compact, foldable arms for rapid deployment and transport
• Multi-radio compatibility for extended operational range
• Operates in high winds and temperatures from -25°C to +38°C
• Operating ceiling up to 8,000 ft ASL

SPECIFICATIONS: VALUE
Max Payload: 10 kg (22 lbs)
Max Takeoff Weight: 25 kg (55 lbs)
Empty Weight: 15 kg (33 lbs)
Hover Endurance: 50 min
Flight Endurance: 50 min
Mas Speed: 38 knots (72 km/h)
Max Range: 10 km+ (DTC Blue SDR)
Operating Ceiling: 2,438 m (8,000 ft ASL)
Wind Resistance: 35 km/h (21 mph)
Operating Temp: -25˚C to +38˚C (-13˚F to 100.4˚F)
